Kyocera ECOSYS P4040dn

2P7/2R0/3PN
1-5-55
4. Remove two screws.
5. Release the hook A by twisting right
upper cover.
6. Release two hooks B by sliding the right
upper cover upward and then remove it.
Figure 1-5-101
7. Remove three screws.
8. Release two hooks by sliding the right
lower cover upward and then remove it.
Figure 1-5-102
Right upper cover
Front cover
Screw
Screw
Hooks B
Hook A
Right lower
cover
Screw
Screw
Screw
Hooks
