2P7/2R0/3PN
1-2-14
1-2-4 Install the memory card (SD card) (option)
Procedure
1. Remove the main PWB assembly from
the machine. (SeePage 1-2-13)
2. SD card is inserted in a SD card slot.
Maximum memory capacity 32 GB.
3. Remove the main PWB assmbly and
the covers.
Figure 1-2-23
SD card
Main PWB assembly
SD card slot
To Next Page
