Kyocera ECOSYS P4040dn

2P7/2R0/3PN
1-5-69
(2) Detaching and refitting the paper feed driving motor unit
Procedure
1. Open the rear cover.
2. Remove the power cord cover by slid-
ing it.
3. Release the hook of the interface cover
and then remove during twisting it.
Figure 1-5-126
4. Pull out the cassette.
? 1?5?127
Interface cover
Power cord
connector cover
Rear cover
Hook
Cassette
Printer
