Kyocera ECOSYS P4040dn

2P7/2R0/3PN
1-5-68
15. Remove the connectors from the
motors and then release the wires from
wire holders.
16. Remove four screws and then remove
the main driving motor unit.
17. Check or replace the main driving motor
unit and refit all the removed parts.
Figure 1-5-125
Connectors
Wires
Wire holders
Main driving motor unit
Screws
