Kyocera ECOSYS P4040dn

2P7/2R0/3PN
1-5-61
29. Remove the screw.
30. Remove two connectors and then
remove the high voltage PWB.
31. Check or replace the high voltage PWB
and refit all the removed parts.
Figure 1-5-113
High voltage PWB
Connector
Connector
Screw
