Kyocera ECOSYS P4040dn

2P7/2R0/3PN
1-5-78
24. Remove three screws and then remove
the controller box cover.
Figure 1-5-143
25. Release the connector and then
release the wire from the hooks.
26. Remove three screws and then remove
the eject unit.
Figure 1-5-144
Controller box cover
Screw
Screw
Screw
Eject unit
Screws
Connector
Hooks
Wire
Grounding
terminal
Screws
