Kyocera ECOSYS P4040dn Service Manual

2P7/2R0/3PN-3
2-2-4
1. Paper sensor 1 (PS1) ........................... Detects the presence of paper in the cassette.
2. Paper sensor 2 (PS2) ........................... Detects the presence of paper in the cassette.
3. Cassette size switch (CSSW) ............... Detects the paper size dial setting of the paper setting dial.
4. Eject full sensor (EFS) .......................... Detects the paper full in the upper tray (Facedown).
5. Registration sensor (RS)....................... Controls the secondary paper feed start timing.
6. Duplex sensor 1 (DUS1) ....................... Detects a paper jam in the duplex section.
7. Duplex sensor 2 (DUS2) ....................... Detects a paper jam in the duplex section.
8. MP paper sensor (MPPS) ..................... Detects the presence of paper on the MP tray.
9. Eject sensor (ES) .................................. Detects a paper misfeed in the fuser or eject section.
10. Fuser pressure release sensor
(FURS) .................................................. Detects the change state of pressure in fuser unit.
11. Fuser thermistor 1 (FUTH1).................. Detects the heat roller temperature at the edge position.
12. Fuser thermistor 2 (FUTH2).................. Detects the heat roller temperature at the center position.
13. Toner sensor (TS) ................................. Detects the amount of toner in the developer.
14. Lift sensor (LS)...................................... Detects the top limit of the bottom plate.
15. Interlock switch (ILSW) ......................... Shuts off 24 V DC power line when the top cover is opened.
16. Rear cover switch (RECSW)................. Detects the opening and closing of the rear cover.
17. Waste toner sensor (WTS).................... Detects when the waste toner box is full.
18. Power source switch (PSSW) ............... Change ON/OFF the power supply of a main PWB, an operation
PWB, etc.
List of correspondences of switch and sensor names
No. Name used in service manual Name used in parts list Part.No.
1 Paper sensor 1 (PS1)
-
(PARTS HIGH VOLTAGE UNIT SP)
-
(302P79405_)
2 Paper sensor 2 (PS2)
3 Cassette size switch (CSSW)
SW.PUSH 7SP03072001+H01
4 Eject full sensor (EFS)
PARTS SENSOR OPT. SP 302P79401_
5 Registration sensor (RS)
-
(PARTS HIGH VOLTAGE UNIT SP)
-
(302P79405_)
6 Duplex sensor 1 (DUS1)
PARTS SENSOR OPT. SP 302P79401_
7 Duplex sensor 2 (DUS2)
-
(PARTS HIGH VOLTAGE UNIT SP)
-
(302P79405_)
8 MP paper sensor (MPPS)
PARTS SENSOR OPT. SP 302P79401_
9 Eject sensor (ES)
-
(FK-7300)
(FK-7300 TW)
-
(302P79302_)
(302P79313_)
*1
10
Fuser pressure release sensor
(FURS)
PARTS SENSOR OPT. SP 302P79401_
11 Fuser thermistor 1 (FUTH1)
-
(FK-7300)
(FK-7300 TW)
-
(302P79302_)
(302P79313_)
*1
12
Fuser thermistor 2 (FUTH2)
13 Toner sensor (TS)
-
(DV-7300)
-
(302P79308_)

Kyocera ECOSYS P4040dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	40 ppm
Printing colors	Black
Maximum duty cycle	150000 pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter XL24E, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	600 sheets
Total output capacity	500 sheets
Maximum input capacity	2600 sheets
Maximum number of input trays	6
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 297 mm
Custom media length	148 - 450 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	-
Mobile printing technologies	Apple AirPrint
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Processor model	465
Processor family	PowerPC
Noise level (idle)	30 dB
Maximum internal memory	1280 MB
Sound pressure level (printing)	50.4 dB
Sound pressure level (quiet mode)	49.6 dB
Display	LCD
Certification	TUV, GS, CE
Product color	Black, White
Display number of lines	5 lines
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (standby)	14 W
Power consumption (printing)	586 W
Power consumption (PowerSave)	1.5 W
Sustainability certificates	ENERGY STAR
Mac operating systems supported	Mac OS X 10.5 Leopard
Other operating systems supported	Android, iOS

Weight and Dimensions

Depth	410 mm
Width	469 mm
Height	320 mm
