Kyocera ECOSYS P4040dn Service Manual

2P7/2R0/3PN
2-3-2
Connector Pin Signal I/O Voltage Description
YC1
1 CD/DAT3 I/O 0/3.3 V DC control signal
Connected to
the SD card
I/F
2 CMD I/O 0/3.3 V DC control signal
3 Vss - - Ground
4 Vdd - 0/3.3 V DC control signal
5 CLK - 0/3.3 V DC control signal
6 Vss - - Ground
7 DAT0 I/O 0/3.3 V DC(pulse) Data bus signal
8 DAT1 I/O 0/3.3 V DC(pulse) Data bus signal
9 DAT2 I/O 0/3.3 V DC(pulse) Data bus signal
10 CD I 0/3.3 V DC control signal
11 COMMON - 0/3.3 V DC control signal
12 WP I 0/3.3 V DC control signal
YC2
A1 E2C_INT I 0/3.3 V DC Transmission clock signal
Connected to
the engine
PWB
B1 C2E_INT O 0/3.3 V DC controller interrupt signal
A2 GND - - Ground
B2 C2E_OFFRD
Y
O 0/3.3 V DC OFF mode sift signal
A3 GND - - Ground
B3 VSYNC I 0/3.3 V DC(pulse) Sub scanning synchronizing signal
A4 E2C_SBSY I 0/3.3 V DC System busy signal
B4 E2C_SDIR I 0/3.3 V DC Serial communication direction signal
A5 C2E_SDAT O 0/3.3 V DC(pulse) Serial communication data input
B5 C2E_SCKN O 0/3.3 V DC(pulse) Serial communication clock signal
A6 E2C_IRN I 0/3.3 V DC Engine interrupt signal
B6 E2C_SDAT I 0/3.3 V DC(pulse) Serial communication data output
A7 GND - - Ground
B7 PLGCLK O 0/3.3 V DC PM control signal
A8 VDATA2N O 0/3.3 V DC Video data signal
B8 VDATA1N O 0/3.3 V DC Video data signal
A9 VDATA2P O 0/3.3 V DC Video data signal
B9 VDATA1P O 0/3.3 V DC Video data signal
A10 GND - - Ground
B10 PDN I 0/3.3 V DC(pulse) Main scanning synchronizing signal
A11 SAMPLE1 O 0/3.3 V DC Sample/Hold signal
B11 SAMPLE2 O 0/3.3 V DC Sample/Hold signal
A12 C2P_SDAT O 0/3.3 V DC Panel transmitted data signal
B12 P2C_SDAT I 0/3.3 V DC Panel received data sjgnal

Kyocera ECOSYS P4040dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	40 ppm
Printing colors	Black
Maximum duty cycle	150000 pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter XL24E, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	600 sheets
Total output capacity	500 sheets
Maximum input capacity	2600 sheets
Maximum number of input trays	6
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 297 mm
Custom media length	148 - 450 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	-
Mobile printing technologies	Apple AirPrint
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Processor model	465
Processor family	PowerPC
Noise level (idle)	30 dB
Maximum internal memory	1280 MB
Sound pressure level (printing)	50.4 dB
Sound pressure level (quiet mode)	49.6 dB
Display	LCD
Certification	TUV, GS, CE
Product color	Black, White
Display number of lines	5 lines
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (standby)	14 W
Power consumption (printing)	586 W
Power consumption (PowerSave)	1.5 W
Sustainability certificates	ENERGY STAR
Mac operating systems supported	Mac OS X 10.5 Leopard
Other operating systems supported	Android, iOS

Weight and Dimensions

Depth	410 mm
Width	469 mm
Height	320 mm
