Print from PC > Printing Data Saved in the Printer
123
Printing Data Saved in the Printer
You can save the print job into the Job Box of this device and print it as necessary. If you configure settings in the
[Job] tab of the printer driver and then print, the print job will be saved in the Job Box (memory) and printing can
be executed at the machine.
To print the job in Job Box, specify the Job Box from a computer and sending the print job, then specify a file within
a Box and printing it, using the operation panel.
You can print the documents from the following boxes.
Private Print Box
Printing Documents from Private Print Box (page 124)
Stored Job Box
Printing Document from Stored Job Box (page 126)
Quick Copy Box
Printing Document from Quick Copy Box (page 128)
Proof and Hold Box
Printing Document from Proof and Hold Box (page 130)
PIN Print Box
Printing Documents from PIN Print Box (page 132)
Universal Print Box
Printing the Documents Stored in the Universal Print Box (page 135)
Specifying the Job Box from a Computer and Storing the Job
1
Click [File] and select [Print] in the application.
The Print dialog box displays.
2
Click the [ ] button of the Name to select the machine from the list.
3
Click the [Properties] button.
The Properties dialog box displays.
4
Click the [Job] tab and select the [Job storage (e-MPS)] check box to set the function.
NOTE
An optional SSD is required to use the Stored Job Box and the Quick Copy Box.
For information on how to use the printer driver software, refer to the following:
Printer Driver User Guide

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kyocera ECOSYS PA4500cx and is the answer not in the manual?

Kyocera ECOSYS PA4500cx Specifications

General IconGeneral
ColorYes
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Duplex printing modeAuto
Time to first page (black, normal)5.1 s
Time to first page (color, normal)6.2 s
Print speed (black, normal quality, A4/US Letter)45 ppm
Duplex print speed (black, normal quality, A4/US Letter)37 ppm
Bitmap fonts-
Printer fontsBarcode, Bitmap, PCL
Printing colorsBlack, Cyan, Magenta, Yellow
Country of originVietnam
Maximum duty cycle100000 pages per month
Recommended duty cycle1500 - 5000 pages per month
Replacement cartridgesTK-5390K, TK-5390C, TK-5390M, TK-5390Y
Number of print cartridges4
Page description languagesJPEG, OpenXPS, PCL 5c, PCL 6, PCL XL, PCLm, PDF, PWG, TIFF, URF, XPS
Total input capacity650 sheets
Total output capacity500 sheets
Maximum input capacity2850 sheets
Paper tray 1 input capacity550 sheets
Total number of input trays2
Maximum number of input trays6
Multi-Purpose tray input capacity100 sheets
Custom media width105 - 216 mm
Maximum print size216 x 356 mm
Custom media length140 - 356 mm
Paper tray media typesLetterhead, Plain paper, Pre-Printed, Thicker paper
Paper tray media weight60 - 220 g/m²
Non-ISO print media sizesLegal (media size), Letter (media size)
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5, B6
Maximum ISO A-series paper sizeA4
USB 2.0 ports quantity3
Wi-FiNo
Cabling technology10/100/1000Base-T(X)
Security algorithmsSNMPv3, TLS
Ethernet LAN data rates10, 100, 1000 Mbit/s
Mobile printing technologiesApple AirPrint, Kyocera Mobile Print, Mopria Print Service
Memory slots1
Storage mediaSSD
Compatible memory cardsSD
Maximum internal memory3000 MB
Sound power level (standby)30 dB
Sound pressure level (printing)54 dB
Sound pressure level (quiet mode)50 dB
DisplayLCD
Control typeButtons
Product colorBlack, White
Market positioningBusiness
Display number of lines5 lines
AC input voltage220 - 240 V
AC input frequency50/60 Hz
Power consumption (max)1289 W
Power consumption (off)0.1 W
Power consumption (ready)11.8 W
Power consumption (printing)576.8 W
Power consumption (PowerSave)0.4 W
Energy Star Typical Electricity Consumption (TEC)0.43 kWh/week
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Other operating systems supportedChromeOS
Operating altitude0 - 3500 m
Storage temperature (T-T)-20 - 40 °C
Operating temperature (T-T)10 - 32.5 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)10 - 80 %
Sustainability certificatesCE, EPEAT Gold, Eco Mark Program, REACH, RoHS, TUV, UKCA, WEEE
Package depth567 mm
Package width702 mm
Package height617 mm
Package weight41000 g
Cables includedAC
Included cartridge capacity (CMY)6000 pages
Included cartridge capacity (black)8000 pages
Weight and Dimensions IconWeight and Dimensions
Depth533 mm
Width394 mm
Height455 mm
