Kyocera ECOSYS PA4500cx User Manual

User Authentication and Accounting (User Login, Job Accounting) > Setting User Login Administration
256
Managing the Users that Print on This Machine from a PC
To manage the users that print on this machine from a PC, the following settings are necessary in the printer
driver. Instructions are based on interface elements as they appear in Windows 10.
1
Display the screen.
1 Select the Windows [Start] button [Windows System Tool] [Control Panel] [Devices and Printers].
NOTE
• For Windows 11, select the [Start] button [All apps] [Windows Tools] [Control Panel]
[Devices and Printers].
• For Windows 8.1, select [Settings] in the Charms Bar on Desktop [Control Panel] [Devices and
Printers].
2 Right-click the printer driver icon of the machine, and click the [Printer properties] menu of the printer
driver.
3 Click [Administrator] on the [Device Settings] tab.
2
Configure the settings.
1 Select [User Login] on the [User Login] tab.
2 Set the User Login Administration.
[Use Specific Login User Name]
This option can be used to specify a user name and password to use the same User login for every
print job. If this option is selected, the user does not have to type the name and password for each
print job.
[Prompt for name]
A screen for entering the user name and password will be displayed when attempting a printing. The
user name and password must be entered each time a printing is attempted.

Kyocera ECOSYS PA4500cx Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.1 s
Time to first page (color, normal)	6.2 s
Print speed (black, normal quality, A4/US Letter)	45 ppm
Duplex print speed (black, normal quality, A4/US Letter)	37 ppm
Bitmap fonts	-
Printer fonts	Barcode, Bitmap, PCL
Printing colors	Black, Cyan, Magenta, Yellow
Country of origin	Vietnam
Maximum duty cycle	100000 pages per month
Recommended duty cycle	1500 - 5000 pages per month
Replacement cartridges	TK-5390K, TK-5390C, TK-5390M, TK-5390Y
Number of print cartridges	4
Page description languages	JPEG, OpenXPS, PCL 5c, PCL 6, PCL XL, PCLm, PDF, PWG, TIFF, URF, XPS
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	2850 sheets
Paper tray 1 input capacity	550 sheets
Total number of input trays	2
Maximum number of input trays	6
Multi-Purpose tray input capacity	100 sheets
Custom media width	105 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 356 mm
Paper tray media types	Letterhead, Plain paper, Pre-Printed, Thicker paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
USB 2.0 ports quantity	3
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Security algorithms	SNMPv3, TLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Kyocera Mobile Print, Mopria Print Service
Memory slots	1
Storage media	SSD
Compatible memory cards	SD
Maximum internal memory	3000 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	54 dB
Sound pressure level (quiet mode)	50 dB
Display	LCD
Control type	Buttons
Product color	Black, White
Market positioning	Business
Display number of lines	5 lines
AC input voltage	220 - 240 V
AC input frequency	50/60 Hz
Power consumption (max)	1289 W
Power consumption (off)	0.1 W
Power consumption (ready)	11.8 W
Power consumption (printing)	576.8 W
Power consumption (PowerSave)	0.4 W
Energy Star Typical Electricity Consumption (TEC)	0.43 kWh/week
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Other operating systems supported	ChromeOS
Operating altitude	0 - 3500 m
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	CE, EPEAT Gold, Eco Mark Program, REACH, RoHS, TUV, UKCA, WEEE
Package depth	567 mm
Package width	702 mm
Package height	617 mm
Package weight	41000 g
Cables included	AC
Included cartridge capacity (CMY)	6000 pages
Included cartridge capacity (black)	8000 pages

Weight and Dimensions

Depth	533 mm
Width	394 mm
Height	455 mm
