Kyocera FS-1120D User Guide

Quick Print
When Multiple pages per sheet is selected, Poster and Scaling are
unavailable.
Profile Options
In the Profiles section, you can select from available profiles to print a job. You
can select from predefined profiles, create your own profile, or import profiles.
You can also rearrange the icons and edit and delete profiles.
Selecting Profiles
The Profiles button at the bottom of the Quick Print tab always includes a
Factory Default profile that returns the driver options to their default settings.
The profiles can include Common Profiles, which are installed as optional
components through the Printer Installation Wizard, and any custom profiles
created. Factory Default and administrator profiles cannot be modified.
1
Click Profiles.
2
In the Profiles dialog box, select a profile.
3
Click Apply.
The side panel displays the options for that profile. If any of the Quick Print
options are not represented in the predefined profile, the Quick Print icon is
unavailable.
4
Click OK.
Saving a Profile
The Save button lets you create your own profiles. You can select the printing
options you want in the driver, then save the driver settings including your
customizations as a profile. You can then use that profile to print the same type
of print job again without having to reselect all the settings. In Printing
Preferences, the Profiles button appears at the bottom of all the tabs.
1
Set the printing options you want for your print job by opening Printing
Preferences and selecting all your driver settings.
2
Click Profiles > Save.
3
To identify the profile, type a Name, select an Icon, and type a Description.
4
Click OK to save the profile.
The newly added profile appears in the Profiles dialog box.
5
Click Apply to use the selected profile for the current print job, or click OK to
close the dialog box.
Note: To reset the printer driver to default settings, select the Factory Default
profile, and click Apply. This clears the settings of a selected profile.
User Guide
3-3

Kyocera FS-1120D Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Time to first page (black, normal)	6 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Memory type	DDR
Memory slots	1
Processor model	405F5
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	544 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	54 dB
Sound pressure level (quiet mode)	49 dB
Total input capacity	300 sheets
Maximum input capacity	550 sheets
Total number of input trays	2
Maximum number of input trays	3
Multi-Purpose tray input capacity	50 sheets
Mobile printing technologies	Not supported
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	7.3 W
Power consumption (printing)	525 W
Power consumption (PowerSave)	4.4 W
Certification	GS, TUV, CE
Product color	Black, White
Custom media width	70 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Printing colors	Black
Maximum duty cycle	20000 pages per month
Page description languages	Epson LQ, IBM ProPrinter, PCL 5e, PCL 6, PJL, PostScript 3
Standard interfaces	USB 2.0
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	250 mm
