Kyocera FS-1370DN Service Manual

2L0
1-4-13
(6)
Developing clutch
does not operate.
Broken developing clutch
coil.
Check for continuity across the coil. If none, replace the develop-
ing clutch.
Defective harness between
developing clutch and con-
trol PWB (YC308), or
improper connector inser-
tion.
Reinsert the connector. Also check for continuity within the con-
nector harness. If none, remedy or replace the harness.
Defective control PWB. Replace the control PWB (See page 1-5-19).
(7)
MP paper feed sole-
noid does not oper-
ate.
Broken MP paper feed sole-
noid coil.
Check for continuity across the coil. If none, replace the MP paper
feed solenoid.
Defective harness between
MP paper feed solenoid
and control PWB (YC309),
or improper connector
insertion.
Reinsert the connector. Also check for continuity within the con-
nector harness. If none, remedy or replace the harness.
Defective control PWB. Replace the control PWB (See page 1-5-19).
(8)
Duplex solenoid does
not operate.
Broken duplex solenoid
coil.
Check for continuity across the coil. If none, replace the duplex
solenoid.
Defective harness between
duplex solenoid and control
PWB (YC317), or improper
connector insertion.
Reinsert the connector. Also check for continuity within the con-
nector harness. If none, remedy or replace the harness.
Defective control PWB. Replace the control PWB (See page 1-5-19).
(9)
Eraser lamp does not
turn on.
Defective harness between
eraser lamp (YC701) and
control PWB (YC316), or
improper connector inser-
tion.
Reinsert the connector. Also check for continuity within the con-
nector harness. If none, remedy or replace the harness.
Defective eraser lamp
(PWB).
Replace the eraser lamp (PWB) (See page 1-5-31).
Defective control PWB. Replace the control PWB (See page 1-5-19).
(10)
Paper indicator is
flashing when paper
is present in the cas-
sette.
Defective paper sensor. Replace the paper sensor.
Defective harness between
paper sensor and control
PWB (YC306), or improper
connector insertion.
Reinsert the connector. Also check for continuity within the con-
nector harness. If none, remedy or replace the harness.
(11)
A paper jam in the
paper feed/convey-
ing section or fuser
section is indicated
when the power
switch is turned on.
A piece of paper torn from
paper is caught around reg-
istration sensor or exit sen-
sor.
Check and remove if any.
Defective registration sen-
sor on the high voltage
PWB.
Replace the high voltage PWB (See page 1-5-24).
Defective exit sensor. Replace the exit sensor.
(12)
Attention indicator is
lit when the top cover
is closed.
Defective interlock switch
on the power source PWB.
Check for continuity across the interlock switch. If there is no con-
tinuity when the interlock switch is on, replace the power source
PWB (See page 1-5-22).
Problem Causes Check procedures/corrective measures

Kyocera FS-1370DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Memory type	DDR
Memory slots	1
Processor model	440F5
Processor family	PowerPC
Maximum internal memory	1152 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Sound pressure level (quiet mode)	49 dB
Total input capacity	300 sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Maximum number of input trays	4
Multi-Purpose tray input capacity	50 sheets
Mobile printing technologies	Not supported
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	11 W
Power consumption (printing)	554 W
Power consumption (PowerSave)	5.5 W
Printing colors	Black
Maximum duty cycle	50000 pages per month
Recommended duty cycle	2800 pages per month
Page description languages	Epson LQ, IBM ProPrinter, PCL 5e, PCL 6, PJL, PostScript 3
Display	LCD
Certification	GS, TUV, CE
Product color	Black, White
Custom media width	70 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Standard interfaces	Ethernet, USB 2.0
Server operating systems supported	Windows 2000 Advanced Server, Windows 2000 Server, Windows MultiPoint Server 2011, Windows SBS 2011 Essentials, Windows SBS 2011 Standard, Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	267 mm
