2L0
1-5-23
5. Remove four screws and then remove the
power source plate from the power source
PWB.
6. Check or replace the power source PWB
and refit all the removed parts.
Caution: The power source film must be
installed in the specified position.
Figure 1-5-32
Power source PWB
Screws
Screws
Power source plate
Power source film
