Kyocera FS-9120DN Installation Guide

28
Available Options
The printer can be equipped with the following options. For instructions on installing individual options, refer
to the documentation included with the option.
Document Finisher
DF-71
Document Fin-
isher DF-75
Paper Feeder PF-70
Paper Feeder PF-75
Memory Card (CF)
Network Interface
Card
(IB-20/21E/22)
Hard Disk Unit
Expansion Memory
(DIMM 32/64/128/
256 MB)
Punch Unit
PH-2A/2B/2C
Reverse Unit RA-1*
*: For face-down high-speed printing.
Document Finisher
DF-73
Serial Interface
Board Kit (IB-11)
Mail Box M-2107
(For DF-71)
HUFPKPUVCNNDQQMࡍ࡯ࠫ㧞㧜㧜㧟ᐕ㧝㧝᦬㧝㧤ᣣޓἫᦐᣣޓඦᓟ㧟ᤨ㧝㧜ಽ

Kyocera FS-9120DN Specifications

General

I/O ports	1 x Fast Ethernet 10/100 Base TX; 1 x High speed bi-directional parallel (IEEE 1284); 1 x USB 2.0 (High-Speed); 1 x KUIO LV Option-Interface slot.
Custom media sizes	88 x 148 mm - 297 x 450 mm
Power requirements	AC 220/240 V 50/60 Hz
Standard input trays	2 x 500
Recommended media weight	60 - 105 g/m²
Power consumption (active)	920 W
Maximum print size	297 x 420 mm
Maximum ISO A-series paper size	A3
Color	No
Print technology	Laser
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Memory slots	2
Storage media	HDD
Processor model	Power PC 750CX
Built-in processor	Yes
Maximum internal memory	544 MB
Internal storage capacity	20 GB
Sound power level (standby)	39 dB
Sound pressure level (printing)	53 dB
Total input capacity	1200 sheets
Maximum input capacity	4200 sheets
Paper tray 2 input capacity	200 sheets
Maximum duty cycle	55000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	160 W
Power consumption (PowerSave)	12 W

Weight and Dimensions

Dimensions (WxDxH)	585 x 639 x 615 mm
