Kyocera FS-9120DN Installation Guide

9
7 Connecting the Power Cord
This section describes procedures and cautions for connecting the power cord.
Notes on Power Supply
• Install the printer near an AC wall outlet, preferably one that can be used for the printer
alone.
• Only use this printer with the supply voltage indicated on the serial number label
attached to the printer’s side panel.
• If an extension cord is used, the total length of the power cord plus the extension cord
should be 5 meters (17 feet) or less.
Power Requirements
Connecting the Power Cord
1
Plug the power cord into the power cord
connector on the rear side of the printer.
2
Connect the other end of the power cord
into a power outlet.
Voltage Frequency Current capacity
120 V (U.S.A. and Canada) 60 Hz (120 V) ±2 % Max. 11.3 A at 120 V (FS-9120DN)
Max. 11.4 A at 120 V (FS-9520DN)
220 to 240 V (European countries,
and the Asia Pacific region), ±10 %
at each voltage
50/60 Hz (220 to 240 V) ±2 % Max. 6.0 A at 220 to 240 V (FS-
9120DN)
Max. 6.1 A at 220 to 240 V (FS-
9520DN)
•Be sure the printer’s power switch is turned off.
•Only use the power cord supplied with the printer.
Be sure to connect to a 3-pronged
grounded power strip.
Power Cord Connector
Power Cord
HUFPKPUVCNNDQQMࡍ࡯ࠫ㧞㧜㧜㧟ᐕ㧝㧝᦬㧝㧤ᣣޓἫᦐᣣޓඦᓟ㧟ᤨ㧝㧜ಽ

Kyocera FS-9120DN Specifications

General

I/O ports	1 x Fast Ethernet 10/100 Base TX; 1 x High speed bi-directional parallel (IEEE 1284); 1 x USB 2.0 (High-Speed); 1 x KUIO LV Option-Interface slot.
Custom media sizes	88 x 148 mm - 297 x 450 mm
Power requirements	AC 220/240 V 50/60 Hz
Standard input trays	2 x 500
Recommended media weight	60 - 105 g/m²
Power consumption (active)	920 W
Maximum print size	297 x 420 mm
Maximum ISO A-series paper size	A3
Color	No
Print technology	Laser
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Memory slots	2
Storage media	HDD
Processor model	Power PC 750CX
Built-in processor	Yes
Maximum internal memory	544 MB
Internal storage capacity	20 GB
Sound power level (standby)	39 dB
Sound pressure level (printing)	53 dB
Total input capacity	1200 sheets
Maximum input capacity	4200 sheets
Paper tray 2 input capacity	200 sheets
Maximum duty cycle	55000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	160 W
Power consumption (PowerSave)	12 W

Weight and Dimensions

Dimensions (WxDxH)	585 x 639 x 615 mm
