Kyocera FS-9120DN Installation Guide

19
Correcting a Paper Jam
If a paper jam occurs while printing, remove the jammed paper as described below. After
removing the jammed paper, open and close the front cover.
Jam in Paper Cassette
1
Pull out the paper cassette.
2
Remove the jammed paper, being careful
not to tear it.
If the paper is torn, remove all the pieces
from the inside the printer.
3
Close the paper cassette.
When removing jammed paper, pull it out carefully so as not to tear it. Torn pieces of
paper are difficult to remove and may be hand to find. Be sure to remove them all.
HUFPKPUVCNNDQQMࡍ࡯ࠫ㧞㧜㧜㧟ᐕ㧝㧝᦬㧝㧤ᣣޓἫᦐᣣޓඦᓟ㧟ᤨ㧝㧜ಽ

Kyocera FS-9120DN Specifications

General

I/O ports	1 x Fast Ethernet 10/100 Base TX; 1 x High speed bi-directional parallel (IEEE 1284); 1 x USB 2.0 (High-Speed); 1 x KUIO LV Option-Interface slot.
Custom media sizes	88 x 148 mm - 297 x 450 mm
Power requirements	AC 220/240 V 50/60 Hz
Standard input trays	2 x 500
Recommended media weight	60 - 105 g/m²
Power consumption (active)	920 W
Maximum print size	297 x 420 mm
Maximum ISO A-series paper size	A3
Color	No
Print technology	Laser
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Memory slots	2
Storage media	HDD
Processor model	Power PC 750CX
Built-in processor	Yes
Maximum internal memory	544 MB
Internal storage capacity	20 GB
Sound power level (standby)	39 dB
Sound pressure level (printing)	53 dB
Total input capacity	1200 sheets
Maximum input capacity	4200 sheets
Paper tray 2 input capacity	200 sheets
Maximum duty cycle	55000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	160 W
Power consumption (PowerSave)	12 W

Weight and Dimensions

Dimensions (WxDxH)	585 x 639 x 615 mm
