Kyocera FS-9500DN Service Manual

FS-9120DN/9520DN
1-1-4
(2) Operator panel
1 GO key
2 CANCEL key
3 ENTER key
4 MENU key
5 Arrow keys
6 Ready indicator
7 Data indicator
8 Attention indicator
9 Message display
0 Interface indicator
! Paper size indicator
@ Paper type indicator
# Paper jam indicator
ENTER
GO
CANCEL
MENU
READY
INTERFACE SIZE TYPE
DATA ATTENTION
Ready
- - - A4 PLAIN
1
8
#
@
97!60
2
3
4
5
Figure 1-1-2
