Kyocera FS-9500DN Service Manual

FS-9120DN/9520DN
1-1-5
1-1-3 Machine cross section
1 Paper feed section
2 Main charging section
3 Laser scanner unit
4 Developing section
5 Transfer and separation section
6 Cleaning and erasing section
7 Fuser section
8 Eject and switchback section
9 Duplex unit
Figure 1-1-3 Machine cross section
Light path
Paper path

Kyocera FS-9500DN Specifications

General

Brand	Kyocera
Model	FS-9500DN
Category	All in One Printer
Language	English
