Kyocera FS-9500DN Service Manual

1-3-4
FS-9120DN/9520DN
1. Place the printer in a proper location.
1. Open the printer front cover all the way.
2. Take out the toner container from the bag.
3. Tap the new toner container on the top 5 to 6
times.
Figure 1-3-6
Figure 1-3-7
Installing the toner container.
Placing the proper location.
Rear: 10 cm (3
15
/16")
Front: 100 cm (39
3
/8")
Right:
70 cm (27
9
/16")
Left:
60 cm (23
5
/8")
Front cover
Toner container
Figure 1-3-8
