1-3-6
FS-9120DN/9520DN
Figure 1-3-12
Connecting the printer to the computer.
There are various ways of connecting the printer to the computer, such as through the parallel interface connecter, USB
cable connecter, or through the network interface connecter.
Installing the waste toner box.
Waste toner box
Figure 1-3-13
1. Install the waste toner box as shown in the figure.
2. Close the front cover.
Printer (Right side)
Parallel interface
Computer
Computer
Power cord
Network cable
USB cable
