1-4-10
FS-9120DN/9520DN
Continued to the next page
Checking the printer cover switch
See page 1-4-14.
>Check Cover SW>
[U038]&InterLock
Setting the amount of slack in the paper
See page 1-4-15.
>Set of Paper >
[U051] Loop
Performing fine adjustment of
the motor speed
See page 1-4-16.
>Adjust Motor >
[U053] Speed
Setting control voltages
See page 1-4-17.
>Adjust High >
[U101] Voltage
Setting toner refresh operation
See page 1-4-18.
>Adjust Toner >
[U112] Refresh
Setting the separation operation mode
See page 1-4-18.
>Setting >
[U114] SC Mode
Checking the toner motor operation
See page 1-4-19.
>Toner MT Move
[U135]
Switching empty toner status detection
See page 1-4-19.
>Ignore Toner
[U136] Empty ###
Setting toner loading operation
See page 1-4-20.
>Set Toner Mode
[U144] ######
Checking sensors
See page 1-4-20.
>Check Sensor >
[U150]
Setting the fixing control temperature
See page 1-4-21.
>Adjust Fixing>
[U161] Heater
Tu rning the fixing heater on
See page 1-4-22.
>Turn Fixing >
[U196]Heater ON
Checking the fixing temperature
See page 1-4-23.
>Display TEMP >
[U199]
Setting the fixing phase control
See page 1-4-22.
>Phase Control
[U198] ###
Setting the paper size for the paper
feeder PF-75
See page 1-4-23.
>Set Bulk Feeder
[U208] Size ##
Setting finisher stack quantity
See page 1-4-24.
>Adjust Finish.>
[U237]Limit ####
Adjusting of punch for the finisher DF-71
See page 1-4-24.
>Finisher >
[U246] Adjust
