FS-9120DN/9520DN
1-4-15
Maintenance
Description
item No.
U051 Setting the amount of slack in the paper
Description
Changes the preset value of the amount of slack of resist or feed.
Purpose
To adjust when the leading edge of the image is not printed or fluctuates irregularly or paper is bent in Z shape.
Method
1. Enter the maintenance mode and press the or key to display "U051".
>Set of Paper >
[U051] Loop
2. Press the key to display the submenu screen.
3. Press the or key to select the item for which the preset value is to be changed.
Display Description Setting range Initial setting
RES FEEDER Amount of slack of resist in feeding from -30 to +20 0
the paper cassette in the printer
RES MPT Amount of slack of resist in feeding from -30 to +20 0
the MP tray
RES DUP Amount of slack of resist in feeding for -30 to +20 -3
duplex printing
FEED MPT Amount of slack of feed in feeding from 0 to +255 110
the MP tray
FEED CASS1 Amount of slack of feed in feeding from 0 to +255 20
the upper cassette in the printer
FEED CASS2 Amount of slack of feed in feeding from 0 to +255 0
the lower cassette in the printer
FEED CASS3 Amount of slack of feed in feeding from 0 to +255 0
the upper cassette in PF-70
FEED CASS4 Amount of slack of feed in feeding from 0 to +255 0
the lower cassette in PF-70
FEED 3000F Amount of slack of feed in feeding from 0 to +255 0
PF-75
4. Press the ENTER key. "_" will blink.
>>RES FEEDER
[051.1] ##
5. Press the or key to move "_" to the digit position at which the value is to be changed and press the or
key to change the preset value.
6. Press the ENTER key. The value is set.
To keep the preset value, press the CANCEL key.
To Next Page
