Maintenance
Description
item No.
FS-9120DN/9520DN
1-4-14
U035 Setting folio size
Description
Sets the type of paper when using Folio or Oficioll.
Purpose
To prevent image loss that occurs depending on the difference of paper type.
Method
1. Enter the maintenance mode and press the or key to display "U035".
2. Press the ENTER key. "?" will be displayed.
3. Press the or key to select folio or oficioll.
>Set Folio Size
[U035]?Folio
4. Press the ENTER key. The setting is set.
To keep the setting, press the CANCEL key.
U038 Checking the printer cover switch
Description
Displays the on-off status of each cover switch.
Purpose
To check if the switches of covers operate correctly.
Method
1. Enter the maintenance mode and press the or key to display "U038".
>Check Cover SW>
[U038]&InterLock
2. Press the key to display the submenu screen.
3. Press the or key to select the switch to check.
Display Switches
Left cover 1 Conveying cover switch (CCSW)
Left cover 2 Side cover switch (SCSW)
Front cover Front cover switch (FRCSW)
Int. Lck Safety switch 1 and 2 (SSW1 and 2)
3. Open and close the cover to check the switch status. 0: Off 1: On
>>Left Cover 1:1
[038.1] 2:1
To Next Page
