FS-9120DN/9520DN
1-4-13
Maintenance
Description
item No.
U031 Checking switches for paper conveying
Description
Displays the on-off status of each paper detection switch on the paper path.
Purpose
To check if the switches for paper conveying operate correctly.
Method
1. Enter the maintenance mode and press the or key to display "U031".
>Check Switches>
[U031]
2. Press the key to display the submenu screen.
3. Press the or key to select the switch to check.
Display Switches
Check SW F1 Feed switch 1 (FSW1)
Check SW F2 Feed switch 2 (FSW2)
Check SW F3 Feed switch 3 (FSW3)
Check SW MP MP feed switch (MPFSW)
Check SW RES Registration switch (RSW)
Check SW EJE Eject switch (ESW)
Check SW BRA Feedshift switch (FSSW)
Check SW DUP Duplex paper conveying switch (DUPPCSW)
4. Turn on or off the switch manually to check the switch status. 0: Off 1: On
>>Check SW F1:0
[031.1] SW F2:0
U032 Checking clutch operation
Description
Turns each clutch on.
Purpose
To check the operation of each clutch.
Method
1. Enter the maintenance mode and press the or key to display "U032".
>Check Clutches>
[U032]
2. Press the key to display the submenu screen.
3. Press the or key to select the clutch to operate.
Display Clutches
PF1 Clutch Upper paper feed clutch (PFCL-U)
PF2 Clutch Lower paper feed clutch (PFCL-U)
PFMP Clutch MP paper feed clutch (MPPFCL)
FEED1 Clutch Feed clutch 1 (FCL1)
FEED2 Clutch Feed clutch 2 (FCL2)
FEED3 Clutch Feed clutch 3 (FCL3)
MPTF Clutch MP feed clutch (MPFCL)
RES Clutch Registration clutch (RCL)
DUPF Clutch Duplex feed clutch (DUPFCL)
4. Press the ENTER key. "Execute" will be displayed and operation will start.
>>PF1 Clutch
[032.1] Execute
5. To stop operation, press the ENTER key or the CANCEL key.
