FS-9120DN/9520DN
1-4-29
Maintenance
Description
item No.
U398 Adjusting left margin of image printing for each paper cassette
Description
Adjusts the left margin of image printing for each paper cassette.
Purpose
To adjust the left margin if it is displaced depending on the paper cassette. Before adjusting this item, use U402
to adjust the left margin of the upper cassette of the printer.
Method
1. Enter the maintenance mode and press the or key to display "U398".
>Set Paper Feed>
[U398] Regist
2. Press the key to display the submenu screen.
3. Press the or key to select the item for which the preset value is to be changed.
Display Description Setting range Initial setting
Cassette 2 Left margin for lower cassette of the printer -600 to +600 0
Cassette 3 Left margin for upper cassette of PF-70 -600 to +600 0
Cassette 4 Left margin for lower cassette of PF-70 -600 to +600 0
Duplex Left margin for duplex printing -600 to +600 0
4. Press the ENTER key. "_" will blink.
>>Cassette 2
[398.1] ###
5. Press the or key to move "_" to the digit position at which the value is to be changed and press the or
key to change the preset value.
If the preset value is increased, the margin will be larger. If the preset value is decreased, the margin will be
smaller.
6. Press the ENTER key. The value is set.
To keep the preset value, press the CANCEL key.
U399 Setting FRPO
Description
Set the firmware again.
Purpose
To change the preset values of firmware.
Method
1. Enter the maintenance mode and press the or key to display "U399".
>Set FRPO >
[U399] Parameter
2. Press the key to display the submenu screen.
3. Press the or key to select the item for which the preset value is to be changed.
4. Press the ENTER key. "_" will blink.
>>FRPO H0
[399.1] ##
5. Press the or key to move "_" to the digit position at which the value is to be changed and press the or
key to change the preset value.
6. Press the ENTER key. The value is set.
To keep the preset value, press the CANCEL key.
To Next Page
