1-5-26

Code Contents

Remarks

Causes Check procedures/corrective measures

FS-9120DN/9520DN

*: Optional

8320

8340

8350

8360

8370

8380

8390

8410

8420

8430

8440

8450

8460

8470

Booklet stitcher* rear jog motor

problem

Booklet stitcher* staple motor prob-

lem

Booklet stitcher* batch processing

motor problem

Booklet stitcher* stapler shift motor

problem

Booklet stitcher* paddle motor prob-

lem

Booklet stitcher* folding problem

Booklet stitcher* backup RAM data

problem

Booklet stitcher* punch motor prob-

lem

Booklet stitcher* shift motor prob-

lem

Booklet stitcher* punch communica-

tion problem

Booklet stitcher* punch sensor prob-

lem

Booklet stitcher* side punch sensor

problem

Booklet stitcher* punch backup RAM

data problem

Booklet stitcher* punch dust sensor

problem

A problem is de-

tected with the

rear jog motor.

A problem is de-

tected with the

staple motor.

A problem is de-

tected with the

batch processing

motor.

A problem is de-

tected with the

stapler shift mo-

tor.

A problem is de-

tected with the

paddle motor.

A problem is de-

tected with the

folding sensor.

A backup RAM

data error is de-

tected.

A problem is de-

tected with the

punch motor.

A problem is de-

tected with the

shift motor.

A problem is de-

tected with the

punch communi-

cation.

A problem is de-

tected with the

punch sensor.

A problem is de-

tected with the

side punch sen-

sor.

A problem is de-

tected with the

punch backup

RAM data.

A problem is de-

tected with the

punch dust sen-

sor.

See the booklet stitcher service manual.
