Kyocera FS-C2026MFP User Manual

Preparation before Use
2-48
4 Click Install Software. The software install wizard
starts up.
From this point, the procedure differs depending
on your version of Windows and your connection
method. Proceed to the correct procedure for your
connection type.
• Express Mode
• Custom Mode
Express Mode
In Express Mode, the installer automatically detects the machine when it is turned on. Use Express Mode for
standard connection methods.
1 In the installation method selection window, select
Express Mode. The print system detection
window appears and the installer detects the
connected machines. If the installer does not
detect a print system, check that the print system
is connected via USB or a network and that it is
turned on. Then return to the print system
detection window.
NOTE: While the information shown in Windows 7, Windows Vista and Windows XP installation dialog boxes
differs slightly, the installation procedure is the same.
2 Select the print system to be installed and click
Next.
3 You can customize the print system name in the
installation settings window. This will be the name
displayed in the Printer window and in the printer
lists displayed in applications. Specify whether to
share the print system name or set the print system
as an existing machine and then click Next.
IMPORTANT: Step 3 only appears if the print system is
connected via a network. It does not appear if the print
system is connected via a USB.

Kyocera FS-C2026MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Total output capacity	- sheets
Maximum input capacity	50 sheets
Internal memory	768 MB
Processor family	PowerPC
Card reader integrated	No
Sound power level (standby)	30 dB
Sound pressure level (printing)	50 dB
Dimensions (WxDxH)	514 x 550 x 580 mm
Power requirements	AC 220 - 240 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Maximum internal memory	1.75 GB
Color all-in-one functions	copy, print
Compatible operating systems	Windows, Mac OS X 10.2 +, Unix, Linux
Maximum print size	216 x 356 mm
Paper tray media types	Envelopes, Plain paper
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	79 W
Power consumption (average operating)	466 W
Certification	TÜV/GS, CE
Maximum duty cycle	65000 pages per month
Grayscale levels	256
Image formats supported	JPG, TIF
Sustainability certificates	ENERGY STAR
Market positioning	Business
