Kyocera FS-C2026MFP User Manual

Preparation before Use
2-49
2
4 A window appears in which you can check the
settings. Check the settings carefully and then
click Install.
NOTE: If the Windows security window appears, click
Install this driver software anyway.
5 A message appears saying that the printer has
been installed successfully. Click Finish to exit the
printer installation wizard and return the CD-ROM
main menu.
If the device setup dialog box appears after you
click Finish, you can specify the settings for items
such as optional features installed in the print
system. You can also specify the device settings
after you exit the installation. For details, refer to
Device Settings in the printer driver operation
guide on the CD-ROM.
This completes the printer driver installation
procedure. Follow the on-screen instructions to
restart the system, if required.
Custom Mode
Use Custom Mode if you want to specify the printer port and select the software to be installed. For example, if
you do not want fonts installed on your computer to be replaced, select Custom Mode and deselect the Fonts
checkbox in the utility tab.
NOTE: Install TWAIN driver or WIA driver on your computer in this mode.
1 Select Custom Mode.
2 Following the instructions in the install wizard
window, select the software packages to be
installed and the specify the port, etc. For details,
refer to Custom Installation in the printer driver
operation guide on the CD-ROM.

Kyocera FS-C2026MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Total output capacity	- sheets
Maximum input capacity	50 sheets
Internal memory	768 MB
Processor family	PowerPC
Card reader integrated	No
Sound power level (standby)	30 dB
Sound pressure level (printing)	50 dB
Dimensions (WxDxH)	514 x 550 x 580 mm
Power requirements	AC 220 - 240 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Maximum internal memory	1.75 GB
Color all-in-one functions	copy, print
Compatible operating systems	Windows, Mac OS X 10.2 +, Unix, Linux
Maximum print size	216 x 356 mm
Paper tray media types	Envelopes, Plain paper
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	79 W
Power consumption (average operating)	466 W
Certification	TÜV/GS, CE
Maximum duty cycle	65000 pages per month
Grayscale levels	256
Image formats supported	JPG, TIF
Sustainability certificates	ENERGY STAR
Market positioning	Business
