6-10
Sending Faxes from PC > Basic Transmission
Basic Transmission
This section explains the basic procedure for sending a fax by Network FAX. An Adobe Acrobat document is sent
as an example.
1
Create the document to be sent.
1 Use an application on your computer to create the document to be sent.
2 Set the original size and orientation.
3 Select [Print] from the File menu. The Print dialog box for the application that you are
using will appear.
2
Select settings in the Print dialog box.
1 Select the product name of the machine (XXX XXX NW-FAX) to be used in the printer
name list.
2 Set the print range and other settings.
3 Click [Properties] to open the Properties window.
Make sure that the number of copies is set to 1. The following screen is an example.
The actual dialog box will vary depending on the application that you are using.
To Next Page
