Table Tilt:
The tilt or angle of the table can be adjusted by disengaging the Stop Stud, loosening the Tension Nut
and tiling the table to the desired angle. Tighten the tension nut to secure the table in desired position.
NOTE: Some models may include a Stop Stud for a 90-degree quick reference (not for precise
alignment) and may need to be removed for precision settings of table.
Figure 29: Table Tilt and Tension Lock
Table Swing:
The Table can be rotated around the column for ideal positioning for many applications. To rotate the
table, loosen the three Column Locks and rotate the table, making sure the Rack and Locks rotate with
the Table. When the table is in position, tighten all three Column Locks.
Figure 30: Column Locks
