6 Correcting Faults
6 Correcting Faults
6.1 Faults and Warnings
Faults and warnings are indicated by displaying the according fault and warning codes. Addi-
tionally faults are displayed by the red blinking of the “Enter’ button.
With the BACK you reach the main window 001. If the fault/warning is still active it will be
displayed by a blinking symbol in the status line of the screen. With the arrow key you
can reach the fault/warning code from the main screen. A fault/warning is displayed until the
according value reaches a normal state. Faults and warnings can be indicated by an optional
digital output module.
NOTICE
With internal or not assignable faults, read data set with LSB Remote Software and send it to
LAMTEC for analysis!
F
W
H
001
/1
Fault
Warning
Main processor
Fault number
Fault probe/probe voltage
trigger 1
