Lane Shark LS-3
ADJUSTMENTS
Directly in Front (Home) Position
The directly in front or “home” position is the position that your
Lane Shark is delivered in. (Refer to Figure 1 for visual reference) The Lane
Shark should ALWAYS be placed in the home position when transporting,
storing or mounting/dismounting from the tractor. Once placed in the
“home” position, make sure all pins are in place and secured.
Figure 1
ABOVE
BACK
SIDE
FRONT
