LaneShark LS-3 - PARTS BREAKDOWN

(850) 610-2870 www.lanesharkusa.com 40
Lane Shark LS-3
REFERENCE MATERIAL
DESCRIPTION QTY PER UNIT TOOLS NEEDED PART NO.
BLADE MATERIAL
15”x3” Rotary Blades
2 N/A
BKLS3000002022A
2-1/16”x1-1/8” Cutter
Bolt
2 N/A
BBLSS000002022A
1-1/8” Lock Washer
2 N/A
BBLSS000002022A
1-1/8” Rotary Cutter
Nut
2 1-1/2” End
Wrench
BBLSS000002022A
PIN MATERIAL
Red Handle Pins 2 N/A RPLS3000002022A
BLACK END CAP MATERIAL
1/4” Pan Head Screws 2 Phillips Head
Screwdriver
LOCKING PIN MATERIAL
Silver Hitch Pins 1 N/A LPLSS000002022A
Compression Spring 1 N/A LPLSS000002022A
Medium Hairpin
Cotter
1 N/A LPLSS000002022A
Large Hairpin Cotter 2 N/A LPLSS000002022A
KICKSTAND MATERIAL
Kickstand 1 N/A KSLS3000002022A
7/16” Flat Washer 2 N/A KSLS3000002022A
7/16” Bolt 1 9/16” End Wrench KSLS3000002022A
7/16” Lock Nut 1 9/16” End Wrench KSLS3000002022A
Clevis Pin - Kickstand 1 N/A KSLS3000002022A
1/2-13 x 1-1/2” Hex
Head Bolt
6 3/4” End Wrench KSLS3000002022A
1/2” Split Lock Washer 6 N/A KSLS3000002022A
1/2” Flat Washer 6 N/A KSLS3000002022A
PIVOT POINT MATERIAL
Pivot Pin Plate 1 N/A PPLS3000002022A
Grease Pins 1 N/A
5/8-11 x 1” Bolts 2 15/16” End Wrench PPLS3000002022A
5/8’ Split Lock Washer 2 N/A PPLS3000002022A
PARTS BREAKDOWN
