Lantronix EDS32PR User Manual

EDS Device Servers User Guide 16
8
E: Lantronix Cables and Adapters
Lantronix P/N Description Applications
500-103 6’ RJ45-to DB9F Included with EDS8/16/32PR for setup or device
connectivity.
Connects the RJ45 RS232 serial ports of EDS8/16/32PR
to a DB9M DTE interface of a PC or serial device.
200.2062 Cable Ethernet CAT5; RJ45, 2 m (6.6 ft) Connects the EDS8/16/32PR Ethernet ports to an
Ethernet switch/hub or is used for cascading from one
EDS8/16/32PR to another.
Connects the EDS8/16/32PR serial RJ45 RS232 ports to
a device using one of the adapters listed below.
200.2063 Cable Ethernet CAT5; RJ45, 5 m (16.4 ft) Connects the EDS8/16/32PR Ethernet ports to an
Ethernet switch/hub or is used for cascading from one
EDS8/16/32PR to another.
Connects the EDS8/16/32PR serial RJ45 RS232 ports to
a device using one of the below listed adapters.
200.2064 Cable Ethernet CAT5; RJ45, 10 m (32.8 ft) Connects the EDS8/16/32PR Ethernet ports to an
Ethernet switch/hub or is used for cascading from one
EDS8/16/32PR to another.
Connects the EDS8/16/32PR serial RJ45 RS232 ports to
a device using one of the adapters listed below.
200.2065 Cable Ethernet CAT5; RJ45, 15 m (49.2 ft) Connects the EDS8/16/32PR Ethernet ports to an
Ethernet switch/hub or is used for cascading from one
EDS8/16/32PR to another.
Connects the EDS8/16/32PR serial RJ45 RS232 ports to
a device using one of the adapters listed below.
200.2066A Adapter RJ45-to-DB25M Allows a standard straight-pinned CAT5 cable to connect
the EDS8/16/32PR RJ45 serial ports to the DB25F DCE
interface of a serial device.
200.2067A Adapter RJ45-to-DB25F Allows a standard straight-pinned CAT5 cable to connect
the EDS8/16/32PR RJ45 serial ports to the DB25M DTE
interface of a serial device.
200.2069A Adapter RJ45-to-DB9M Allows a standard straight-pinned CAT5 cable to connect
the EDS8/16/32PR RJ45 serial ports to the DB9F DCE
interface of a serial device.
200.2070A Adapter RJ45-to-DB9F Allows a standard straight-pinned CAT5 cable to connect
the EDS8/16/32PR to the DB9M DTE interface of a PC
or serial device.
ADP010104-01 Adapter "Rolled" RJ45-to-RJ45 Allows a standard straight-pinned CAT5 cable to connect
the EDS8/16/32 to an RJ45 console port on products
from Cisco and other manufacturers.

Lantronix EDS32PR Specifications

General

Certification	UL/CUL, FCC, CE, TUV, C-Tick, GS, CB scheme, VCCI FCC Part 15 Statement Class A Device, ICES-003 Class A Device, C-Tick, VCCI, CE Marking, UL-CUL Mark, TUV-GS Mark, RoHS FCC CFR 47 Part 15 Subpart B, ICES-003 Issue 4, AS/NZS CISPR 22, VCCI V-3, EN55022, EN61000-3-2, EN61000-3-3, EN55024, EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-8, EN61000-4-11
Networking standards	IEEE 802.3
Serial interface type	RS-232
Serial ports quantity	32
Ethernet LAN data rates	10, 100 Mbit/s
Cabling technology	10/100Base-T(X)
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security algorithms	SSH
Supported network protocols	HTTP, HTTPS, FTP, TFTP, Telnet, TCP, UDP, LPD, XML, DHCP, SSHv2, SSLv3, SNMPv2, AutoIP, RSS, ARP, ICMP, SYSLOG, AES, SMTP, DNS, BOOTP, Traceroute
Built-in processor	Intel XScale IXP420
Processor frequency	266 MHz
Compatible operating systems	Windows 98/ME/NT/2000/XP/Vista
Flash memory	8 MB
RAM capacity	64 MB
LED indicators	LAN
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Input voltage	100 - 240 V
Safety	UL 60950-1, CSA-22.2 No.60950-1-03, EN60950-1, CB Report - IEC 60950-1
