Lantronix EDS32PR User Manual

Contents
EDS Device Servers User Guide 4
Finding a Suitable Location _______________________________________________ 24
Connecting the EDS4100_________________________________________________ 24
4: Installation: EDS8PR, EDS16PR and EDS32PR 26
Package Contents __________________________________________________ 26
User-Supplied Items ________________________________________________ 26
Identifying Hardware Components______________________________________ 27
Serial Ports____________________________________________________________ 28
Ethernet Port __________________________________________________________ 28
LEDs_________________________________________________________________ 28
Reset Button___________________________________________________________ 29
Physically Installing the EDS8/16/32PR__________________________________ 29
Finding a Suitable Location _______________________________________________ 29
Connecting the EDS8/16/32PR ____________________________________________ 29
5: Getting Started 31
Using DeviceInstaller ________________________________________________ 31
Starting DeviceInstaller __________________________________________________ 31
Viewing EDS Properties __________________________________________________ 32
Configuration Methods_______________________________________________ 34
Configuring from the Web Manager Interface _________________________________ 34
Configuring via an SSH/Telnet Session or Serial Port Using the CLI _______________ 34
Configuring from the XML Interface _________________________________________ 35
6: Configuration Using the Web Manager 36
Accessing the Web Manager through a Web Browser ______________________ 36
Navigating Through the Web Manager __________________________________ 38
Device Status Page _________________________________________________ 47
7: Network, Line, Tunnel, and Terminal Settings 48
Network Configuration Page __________________________________________ 48
Line Settings Pages_________________________________________________ 51
Line – Statistics Page____________________________________________________ 52
Line - Configuration Page ________________________________________________ 53
Line – Command Mode Page _____________________________________________ 55
Tunnel Pages______________________________________________________ 56
Tunnel – Statistics Page _________________________________________________ 56
Tunnel – Serial Settings Page _____________________________________________ 57
Tunnel – Start/Stop Characters Page _______________________________________ 59
Tunnel – Accept Mode Page ______________________________________________ 61
Tunnel – Connect Mode Page _____________________________________________ 63

Lantronix EDS32PR Specifications

General

Certification	UL/CUL, FCC, CE, TUV, C-Tick, GS, CB scheme, VCCI FCC Part 15 Statement Class A Device, ICES-003 Class A Device, C-Tick, VCCI, CE Marking, UL-CUL Mark, TUV-GS Mark, RoHS FCC CFR 47 Part 15 Subpart B, ICES-003 Issue 4, AS/NZS CISPR 22, VCCI V-3, EN55022, EN61000-3-2, EN61000-3-3, EN55024, EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-8, EN61000-4-11
Networking standards	IEEE 802.3
Serial interface type	RS-232
Serial ports quantity	32
Ethernet LAN data rates	10, 100 Mbit/s
Cabling technology	10/100Base-T(X)
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security algorithms	SSH
Supported network protocols	HTTP, HTTPS, FTP, TFTP, Telnet, TCP, UDP, LPD, XML, DHCP, SSHv2, SSLv3, SNMPv2, AutoIP, RSS, ARP, ICMP, SYSLOG, AES, SMTP, DNS, BOOTP, Traceroute
Built-in processor	Intel XScale IXP420
Processor frequency	266 MHz
Compatible operating systems	Windows 98/ME/NT/2000/XP/Vista
Flash memory	8 MB
RAM capacity	64 MB
LED indicators	LAN
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Input voltage	100 - 240 V
Safety	UL 60950-1, CSA-22.2 No.60950-1-03, EN60950-1, CB Report - IEC 60950-1
