Lantronix EDS32PR User Manual

Contents
EDS Device Servers User Guide 6
MIB-II Network Statistics Page____________________________________________ 114
IP Sockets Page_______________________________________________________ 115
Diagnostics: Ping Page _________________________________________________ 116
Diagnostics: Traceroute Page ____________________________________________ 117
Diagnostics: DNS Lookup Page___________________________________________ 118
Diagnostics: Memory Page ______________________________________________ 118
Diagnostics: Buffer Pools ________________________________________________ 120
Diagnostics: Processes Page ____________________________________________ 120
Real Time Clock Page ______________________________________________ 122
System Page _____________________________________________________ 123
11: Advanced Settings 125
Email Pages______________________________________________________ 125
Email Statistics Page ___________________________________________________ 125
Email Configuration Page _______________________________________________ 126
CLI Pages _______________________________________________________ 128
Command Line Interface Statistics Page ____________________________________ 128
Command Line Interface Configuration Page ________________________________ 129
XML Pages ______________________________________________________ 131
XML: Export Configuration Page __________________________________________ 131
XML: Export Status ____________________________________________________ 133
XML: Import Configuration Page __________________________________________ 135
12: Updating Firmware 141
Obtaining Firmware ________________________________________________ 141
Upgrading Using DeviceInstaller ______________________________________ 141
Loading New Firmware _________________________________________________ 141
Updating the Boot Loader from DeviceInstaller _______________________________ 141
Updating Firmware _____________________________________________________ 142
A: Factory Default Configuration 143
Network Configuration Settings _______________________________________ 143
Serial Port Line Settings ____________________________________________ 143
Tunnel Settings ___________________________________________________ 144
Serial Settings ________________________________________________________ 144
Start/Stop Characters___________________________________________________ 145
Accept Mode _________________________________________________________ 145
Connect Mode ________________________________________________________ 145
Disconnect Mode ______________________________________________________ 146
Packing Mode_________________________________________________________ 146
Modem Emulation _____________________________________________________ 147

Lantronix EDS32PR Specifications

General

Certification	UL/CUL, FCC, CE, TUV, C-Tick, GS, CB scheme, VCCI FCC Part 15 Statement Class A Device, ICES-003 Class A Device, C-Tick, VCCI, CE Marking, UL-CUL Mark, TUV-GS Mark, RoHS FCC CFR 47 Part 15 Subpart B, ICES-003 Issue 4, AS/NZS CISPR 22, VCCI V-3, EN55022, EN61000-3-2, EN61000-3-3, EN55024, EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-8, EN61000-4-11
Networking standards	IEEE 802.3
Serial interface type	RS-232
Serial ports quantity	32
Ethernet LAN data rates	10, 100 Mbit/s
Cabling technology	10/100Base-T(X)
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security algorithms	SSH
Supported network protocols	HTTP, HTTPS, FTP, TFTP, Telnet, TCP, UDP, LPD, XML, DHCP, SSHv2, SSLv3, SNMPv2, AutoIP, RSS, ARP, ICMP, SYSLOG, AES, SMTP, DNS, BOOTP, Traceroute
Built-in processor	Intel XScale IXP420
Processor frequency	266 MHz
Compatible operating systems	Windows 98/ME/NT/2000/XP/Vista
Flash memory	8 MB
RAM capacity	64 MB
LED indicators	LAN
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Input voltage	100 - 240 V
Safety	UL 60950-1, CSA-22.2 No.60950-1-03, EN60950-1, CB Report - IEC 60950-1
