Lantronix XPort User Guide

4: Configuration Using Web Manager
XPort® Device Server User Guide 29
921600.
Note: Baud rates 460800 and 921600 are available for
selection only when CPU performance mode is set to High."
Data Bits
Indicates the number of bits in a transmitted data package.
The default is 8.
Parity
Checks for the parity bit. The default is None.
Stop Bits
The stop bit follows the data and parity bits in serial
communication. It indicates the end of transmission. The
default is 1.
Pack Control
Enable Packing
Select to enable packing on the XPort module.
Two firmware-selectable packing algorithms define how and
when packets are sent to the network.
The standard algorithm is optimized for applications in which
the unit is used in a local environment, allowing for very small
delays for single characters, while keeping the packet count
low.
The alternate packing algorithm minimizes the packet count
on the network and is especially useful in applications in a
routed Wide Area Network (WAN). Adjusting parameters in
this mode can economize the network data stream.
Disabled by default.
Idle Gap Time
Select the maximum time for inactivity. The default time is
12 milliseconds.
Match 2 Byte Sequence
Use to indicate the end of a series of data to be sent as one
group. The sequence must occur sequentially to indicate end
of the data collection to the XPort device services. The default
is No.
Match Bytes
Use to indicate the end of a series of data to be sent as one
group. Set this value to 00 if specific functions are not needed.
Send Frame Immediate
After the detection of the byte sequence, indicates whether to
send the data frame or the entire buffer. Select Yes to send
only the data frame. The default setting is No.
Send Trailing Bytes
Select the number of bytes to send after the end-of-sequence
characters. The default is None.
Flush Input Buffer (Serial to Network)
With Active Connect
Select Yes to clear the input buffer with a connection that is
initiated from the device to the network. The default is No.
With Passive Connect
Select Yes to clear the input buffer with a connection initiated
from the network to the device. The default is No.
At Time of Disconnect
Select Yes to clear the input buffer when the network
connection to or from the device is disconnected. The default
is No.

Lantronix XPort Specifications

General

Data Link Protocol	Ethernet, Fast Ethernet
Connectivity Technology	Wired
Form Factor	Embedded
Category	Embedded Systems
Interface	Serial
Serial Ports	1
Operating Temperature	0°C to 70°C
