Lantronix XPort User Guide

XPort® Device Server User Guide 10
1. Using This Guide
Purpose and Audience
This user guide covers these Lantronix® DeviceLinx® XPort® device server modules:
Model
Part Numbers
XPort-03
XP1001000-03R
XP1002000-03R
XP100200S-03R
XPort-04
XP1001000-04R
XP1002000-04R
XP100200S-04R
XPort-05
XP1001000-05R
XP1002000-05R
XP100200S-05R
It provides the information needed to configure, use, and update the XPort firmware and is
intended for OEMs and system integrators who are embedding the XPort module in their end
product designs.
Chapter Summary
The remaining chapters in this guide include:
Chapter
Description
2: Introduction
Describes the main features of the XPort module and the
protocols it supports.
3: Using DeviceInstaller
Provides information for getting your unit up and running,
using DeviceInstaller to assign an IP address.
4: Configuration Using Web
Manager
Details using the Web Manager to set parameters such as port
and server properties.
5: Configuration via Telnet or Serial
Port (Setup Mode)
Provides instructions for accessing Setup Mode (command
line interface) using a Telnet connection through the network
or a terminal or terminal emulation program through the serial
port.
6: Setup Mode: Server
Configuration
Details the network (server) settings
7: Setup Mode: Channel
Configuration
Details the serial port settings.
8: Setup Mode: Advanced Settings
Details email, expert, and security settings and explains how
to reset the unit to factory default values.

Lantronix XPort Specifications

General

Data Link Protocol	Ethernet, Fast Ethernet
Connectivity Technology	Wired
Form Factor	Embedded
Category	Embedded Systems
Interface	Serial
Serial Ports	1
Operating Temperature	0°C to 70°C
