LAUNCH X-431 Throttle User Manual
39
9
Combine – this option is mostly used in graph merge status for data
comparison.
In this case, different items are marked in different colors.
On-screen Buttons:
Single graph:
Tap it to view the waveform.
Fig. 5-23
•
Min/Max
: Tap “Min/Max” to define the maximum/minimum value. Once the
value goes beyond the specified value, the system will alarm.
Graph
: Tap it to view the waveform.
Fig. 5-24
