X-431 Throttle User Manual
89
10 Running indicator
It remains steady green after the Scopebox
is running.
11 Power indicator
It keeps steady red after the Scopebox is
powered on.
12.2.2 Scopebox accessories
The Scopebox includes the secondary pickup cable for 4-channel oscilloscope,
crocodile clips for 4-channel oscilloscope, etc. See Table 12-2.
As the product configuration can be different, the accessories included with the
product may differ from the accessories listed on this manual. Please see the
packing list attached to the product for the detailed accessories.
Table 12-2 Accessory checklist
No. Name Picture
1
Secondary ignition pickup for
4-channel oscilloscope
2
Crocodile clips for 4-channel
oscilloscope
3 Direct ignition extension cable
4
6-way universal guide line for
4-channel oscilloscope
5 BNC to 4mm connector test cable
