LAUNCH Electronic Two-post User’
9
Fig 2f
3 Operation Description
3.1 Precautions for vehicle repair
work
Different vehicles have different center of gravity
positions. First understand the position of center
of gravity, and when the vehicle enters into the
lift, make its center of gravity close to the plane
formed by two columns. Adjust the swing arm,
and make the lifting pad support onto the lifting
point of the vehicle.
Carefully read the warming symbol.
The hydraulic valves have been adjusted before
ex-factory, and the user can’t make
self-adjustment, otherwise it will be responsible
for all the consequences generated.
Based on the production needs, some
specifications in the instruction manual are
subjected to change without notice
3.2 Preparation before Operation
Lubricate contact surface of the carriage with
general-purpose lithium grease
（
GB7324-87
）
.
All sliding surface should be coated evenly from
the top to bottom.
Fill hydraulic oil N32 or N46 to the oil reservoir of
the power unit.
3.3 Inspection before operation
Check to see if the motor power is installed properly.
Check to see if all the connection Bolt s are fastened.
Note: Don’t operate the lift with damaged
cables or damaged and missing part, until it is
inspected and repaired by the professionals.
