3.4 Lifting the Vehicle
 Keep work area clean, don’t operate the lift in
cluttered work area.
 Lower the carriage to the lowest position.
 Reduce the swing arm to the minimum length.
 Swing the arm along the route of the vehicle
 Move the vehicle to the location between the two
columns
 Swing the arm and put the lifting pad below the
recommended lifting point, and adjust the height
of lifting pad to touch lifting point of vehicle
 Press the UP button on the electric control box,
slowly lift the vehicle to ensure the load balance,
and then raise the lift to the required height.
 Release the UP button and the carriage will
stop.
 Press the DOWN button to engage the safety
lock of carriage. At this time, the vehicle can be
repaired.
Note:
 Before operation, the safety locking devices
must be Inspected.1) The gear blocks of the
arm end must engage the gear block of the
restraint shaft.2)No broken strand in the steel
cable. 3)No deformation in the arm pad.
 When lifting the vehicle, all the swing arms
must be used.
 Before lifting the vehicle, check all the
hydraulic hose and fittings for oil leakage. In
case of leakage, please don’t use the lift.
Remove the fitting with leakage and re-seal.
Re-install the fitting and check if oil leakage
still exists.
 After the vehicle is lifted, when adding or
removing any major heavy object, use jack
stand to maintain the balance of the vehicle.
3.5 Lowering the Vehicle
 Clean the work area before lowering the vehicle.
 First press the UP button to raise the vehicle a
little, then press and hold the UNLOCK button to
disengage the safety lock, and then press
DOWN button to lower the vehicle.
 Lower the vehicle till the swing arm down to the
bottom and the lifting pads leave the vehicle
chassis, and then release the two buttons.
 The swing arms under the vehicle must be fully
shrunk
Note: When the lift doesn’t work, you must
switch off the power.
