Launch TLT235SBA User Manual

LAUNCH Electronic Two-post User’
s Manual
2
TLT235SCA(U)
(Symmetric
installation)
2424 mm
95.4 in
3392 mm
133.5 in
TLT235SCA(U)
(Asymmetric
installation)
3500 kg
7875 lb
1850
mm
72.8 in
≤ 50s
≥ 20s
≤ 40s
670kg
1477 lb
2378 mm
93.6 in
3544mm
139.5 in
3840 mm
151.2 in
Noise:
Working noise: ≤ 75dB （ A ）
Power unit:
Working pressure: 16MPa (TLT235SBA)
16Mpa (TLT235SBA(E))
16Mpa(TLT235SCA(U))
18MPa （ TLT240SBA ）
18MPa （ TLT240SCA ）
1.5 Environmental Requirement
Working temperature ： -5 ℃～ +40 ℃ Relative humidity: Temperature +30 ℃， relative humidity 80%
Transport/storage temperature ： -5 ℃～ +40 ℃ Height above sea level ： No more than 2000m
2. Lift Structure
2.1 Lift structures are shown as below：
：：
：
Model Description
TLT235SBA floor-plate 2-post lift
3.5T Electronic symmetric floor-plate 2-post lift (Fig1a 、 Fig2a)
TLT240SBA floor-plate 2-post lift
4.0T Electronic symmetric floor-plate 2-post lift (Fig1a 、 Fig2a)
TLT235SBA(E) floor-plate 2-post lift
3.5T Electronic symmetric wide floor-plate 2-post lift(Fig1b 、 Fig2b)
TLT240SCA clear-floor 2-post lift
4.0T Electronic clear-floor 2-post lift (Fig1c 、 Fig2c)
TLT235SCA(U) clear-floor 2-post lift
3.5T Electronic clear-floor 2-post lift (Fig1d 、 Fig2d)
Electrical parameters of the machine ：
：：
：
Motor (optional)
Voltage ： According to client’s requirement
Single phase: 110V/60Hz 2.2kW ； 220V/50Hz 2.2 kW
Single phase: 200V/60Hz 2.2 kW
Three phase 380V/50Hz 2.2 kW
