LAUNCH Electronic Two-post User’
s Manual
25
Fig 9b
Fig 9c
Short screw end, double
nuts tightened
Long screw end,
adjustable
Steel cable
(C) Diagtools; www.diagtools.eu; diagtools@diagtools.lv; Pernavas 43A, Riga, Latvia, LV-1009; +37129416069
