Launch TLT235SBA User Manual

LAUNCH Electronic Two-post User’
s Manual
49
902
201021792
TLT235SCA(U) offside column
904
103202891 Protective cover inside the column
906 103200960 Electromagnet
907 104120078 Electromagnet cover
908 103010498 Screw M5×8
909
103202811
Connecting bracket Ⅰ
910 103040110 Flat washer12
911 103040044 Spring washer12
912 103020104 Bolt M12×35
913
103202812
Connecting bracket Ⅱ
914 103040123 Flat washer10
915 103040122 Spring washer10
916 103020120 Bolt M10×20
918
103010429
Screw M4×25
919 103201545 Bracket
920
105990008 Limit switch
921
103202817 Inner top beam
922 103202818 Outer top beam
923 201011258
Bush Ⅰ
924
103060342
Pin 3×26
925 201011170 Long bar
926
201011172
Supporting pin of long bar
927 201012602
Bush Ⅱ
928 104090045 Pulley
929
103050035
Returning ring 25
930
103200967 Symmetric axle
103200966 Asymmetric axle
931
103020099 Bolt M6×20
932 103040027 Spring washer6
933
103040133
Flat washer6
934 103200942 Safety plate
935 103202520 Supporting block
936
103201073
Bracket for extension sleeve
937
103201070
Bottom cover of column
938 103010582 Anchor bolt M18×160
103020123 Anchor bolt M18×160
939 103260257 Steel cable
941 103020090 Screw M6×10
942 103202810 Fixing plate of power unit
943 102100185
Roller type limit switch
944 103010426 Screw M4×12
945 201014616 Limit bottom plate
