PowerTrace Serial User´s Guide 2 9
©1989-2018 Lauterbach GmbH
This example is based on an LS1046 target
; JTAG DEBUGGER SETUP
SYStem.RESet
SYStem.JtagClock ...
SYStem.CPU ...
SYStem.Up
; TARGET PERIPHERAL SETUP
Data.Set ...
SYStem.Option ...
; TARGET APPLICATION SETUP
Data.LOAD.ELF ...
Register.Set PC ...
Go.direct main
;(A) TRACE32 TRACE SETUP
SYStem.CONFIG.TRACEPORT.Type.PCIE.
TRACEPORT.PortType PCIE
Analyzer.Init
;(B) TARGET PCIe SETUP (script)
DO setup_ls_pcie "0x03600000" "0x5000000000"
;(C) TARGET TRACE SETUP (script)
&EtrAxiBase=0x5049000000
DO etr_utility.cmm ETR1 set DAB &EtrAxiBase
DO etr_utility.cmm" ETR1 set RSZ 0x8
DO etr_utility.cmm" ETR1 set AXICTL 0x00000F00 0x00000FBF
Trace.METHOD Analyzer
ETM.Trace ON
ETM.ON
;Test the state of the trace channel
PRINT Analyzer.ISCHANNELUP()
ENDDO
