PowerTrace Serial User´s Guide 4 3
©1989-2018 Lauterbach GmbH
Technical Data
In this section:
• PowerTrace Serial Accessory Sets
• Electrical Specification for PowerTrace Serial
PowerTrace Serial Accessory Sets
LA-3521 - ACC-PTSERIAL-ETM 1-6
LA-1235 - 40pin Flex Cable
Product number Product code Includes
LA-3521 ACC-PTSERIAL-ETM 1-6 LA-1235 (40pin flex cable)
LA-2770 (Mipi34-ARM20-adapter)
LA-2114 (34pin Half-size-Cable
LA-3522 ACC-PTSERIAL-ETM 7-8 LA-1239 (80pin flex cable)
Manufacturer Samtec
Type 30 AWG Twinax
Impedance 100
Capacitance 48.9 pF/m
Inductance 0.518 uH/m
Propagation Delay 4.79 ns/m
Shield Braid, Silver Plated Copper
Dielectric FEP
Jacket PVC
Length 53 cm
