PowerTrace Serial User´s Guide 2 0
©1989-2018 Lauterbach GmbH
Configuration Guide
Target specific adapter configuration might be necessary, if
• it is not possible to get a PCIe link
• the lane speed is below the maximum possible
• the PCIe error rate is high => high bandwidth reduction
Start with the first configuration (#1) and increase step by step (#2 => #3 ...). To verify the configuration the
data eye scanner should be used (Analyzer.ShowFocusEye).
Always first disable the switches before you enable the next configuration. Don’t
have more than one switch enabled within a group. Changing the configuration
must be done like this:
100 : current configuration
000 : set temporary configuration
001 : set final configuration
