PowerTrace Serial User´s Guide 8

Adapter for AGBT (LA-3556)

Connector Function

A AUTO26 debug connector

B JTAG16 debug connector

C Target connector

D PowerTrace Serial connector for Serial Port 1

Both debug connectors, AUTO26 [A] and the JTAG16 [B] hold the same debug

signals coming from the target connector [C]. Only one debug connector at the

time must be used.
