Display

PERSISTENCE These menus appear when “Persistence Setup” is selected from

“DISPLAY SETUP”.

Persistence

To select whether persistence is applied to all or to the top two

traces.

Persist for

For selecting the persistence duration, in seconds.

The number of sweeps accumulated — up to 1 million — is

displayed below the grid.
